The high flow rate cartridges have 6 inch/152mm large diameter, and is coreless, single open-ended with an inside to outside flow direction. The large diameter with big filter area can reduce the number of filter cartridges and the dimension of housing required. The long service life and high flow rate can bring low investment and less manpower in many applications.
Online
Gradient pore structure
Up to 110M3/H flow rate per filter cartridge for water filtration
Maximum 50% reduction of filter system
All contaminants can be removed within the cartridge because of the flow direction.
Prefiltration of RO, Pretreatment of sea water desalination
Condensate water filtration, hot water recovery in power generation
Solvents, and water filtration in Bio-pharm market
The filtration of bottled water, high Fructose, edible oil, soft drinks, and milk
Paints and coatings, Petrochemical, Refineries
